Neo

• Takeoff Weight

• Approx. 135 g

• Dimensions

• 130×157×48.5 mm (L×W×H)

• Max Ascent Speed

• 0.5 m/s (Cine mode)
  2 m/s (Normal mode)
  3 m/s (Sport mode)

• Max Descent Speed

• 0.5 m/s (Cine mode)
  2 m/s (Normal mode)
  2 m/s (Sport mode)

• Max Horizontal Speed (near sea level, no wind)

• 6 m/s (Normal mode)
  8 m/s (Sport mode)
  16 m/s (Manual mode)



• Max Takeoff Altitude

• 2000 m

  Measured in a windless environment when taking off from an altitude of 2000 m and ascending vertically by 120 m, using Sport mode, and from 100% battery level until 20%. Data is for reference only. Always pay attention to reminders on the camera view during your flight.

• Max Flight Time

• Approx. 18 mins (approx. 17 mins with the Propeller Guards)*
  Each battery allows Neo to perform at least 20 palm takeoff and landing for shoots in succession**

  * Measured when flying forward at a speed of 2 m/s in a windless environment 20 m above sea level, with camera parameters set to 1080p/30fps, video mode off, and from 100% battery level until 0%. Results may vary depending on the environment, actual use, and firmware version.
  ** Measured after DJI Neo is activated, with a fully charged battery and default settings, and using Circle, Rocket, and Expanse modes, and is for reference only.


• Max Hovering Time

• Approx. 18 mins (approx. 17 mins with the Propeller Guards)

  Measured when hovering in a windless environment 20 m above sea level, with camera parameters set to 1080p/30fps, video mode off, and from 100% battery level until 0%. Results may vary depending on the environment, actual use, and firmware version.

• Max Flight Distance

• 7 km‌

  Measured when flying forward at a speed of 8 m/s in a windless environment 20 m above sea level, with camera parameters set to 1080p/30fps, video mode off, and from 100% battery level until 0%. Results may vary depending on the environment, actual use, and firmware version.

• Max Wind Speed Resistance

• 8 m/s (Level 4)

• Operating Temperature

• -10° to 40° C (14° to 104° F)

• Class

• C0 (EU)

Camera

• Image Sensor

• 1/2-inch image sensor

• Lens

• FOV: 117.6°
  Format Equivalent: 14 mm
  Aperture: f/2.8
  Focus: 0.6 m to ∞

• ISO Range

• 100-6400 (Auto)
  100-6400 (Manual)

• Shutter Speed

• Video: 1/8000-1/30 s
  Photo: 1/8000-1/10 s

• Max Image Size

• 12 MP Photo
  4000×3000 (4∶3)
  4000×2256 (16∶9)

• Still Photography Modes

• Single/Timed Shot

• Photo Format

• JPEG

• Video Resolution

• EIS Off:
  4K (4:3): 3840×2880@30fps
  1080p (4:3): 1440×1080@60/50/30fps

  EIS On:
  4K (16:9): 3840×2160@30fps
  1080p (16:9): 1920×1080@60/50/30fps

• Video Format

• MP4

• Max Video Bitrate

• 75Mbps

• Supported File System

• exFAT

• Color Mode

• Normal

• EIS

• Supports RockSteady, HorizonBalancing, and turning stabilization off.*

  * When using a 16:9 aspect ratio, only RockSteady or HorizonBalancing can be enabled. Stabilization is not available in 4:3 aspect ratio. When stabilization is turned off, footage captured supports offline stabilization with Gyroflow.

Gimbal

• Stabilization

• Single-axis mechanical gimbal (tilt)

• Mechanical Range

• Tilt: -120° to 120°

• Controllable Range

• Tilt: -90° to 60°

• Max Control Speed (tilt)

• 100°/s

• Angular Vibration Range

• ±0.01°

• Image Roll Correction

• Supports correction of footage recorded on Neo
  Live view correction is unavailable only when used with additional accessories.

Sensing

• Sensing Type

• Downward visual positioning

• Downward

• Precise Hovering Range: 0.5-10 m

• Operating Environment

• Downward:
  Non-reflective, discernible surfaces with diffuse reflectivity of >20% (such as walls, trees, or people)
  Adequate lighting (lux > 15, normal indoor lighting conditions)

Wi-Fi:

• Protocol

• 802.11a/b/g/n/ac

• Operating Frequency

• 2.400-2.4835 GHz
  5.725-5.850 GHz

  Operating frequency allowed varies among countries and regions. Please refer to local laws and regulations for more information.

• Transmitter Power (EIRP)

• 2.4 GHz:
  < 20 dBm (FCC/CE/SRRC/MIC)

  5.8 GHz:
  ＜20 dBm (FCC/SRRC)
  ＜14 dBm (CE)

• Effective Operating Range

• 50 m

  Tested in an outdoor open environment free of interference. The video transmission distance varies by operating environment.

Bluetooth

• Protocol

• Bluetooth 5.1

• Operating Frequency

• 2.400-2.4835 GHz

  Operating frequency allowed varies among countries and regions. Please refer to local laws and regulations for more information.

• Transmitter Power (EIRP)

• ＜ 10 dBm

Battery

• Capacity

• 1435 mAh

• Weight

• Approx. 45 g

• Nominal Voltage

• 7.3 V

• Max Charging Voltage

• 8.6 V

• Type

• Li-ion

• Energy

• 10.5 Wh

• Charging Temperature

• 5° to 40° C (14° to 104° F)

• Charging Time

• When Using the Two-Way Charging Hub (60W max charging power): Approx. 60 minutes to charge three batteries simultaneously from 0% to 100%
  When Directly Charging Neo (15W max charging power): Approx. 50 minutes to charge from 0% to 100%

Charger

• Recommended Charger

• DJI 65W Portable Charger
  USB Power Delivery charger

Battery Charging Hub

• Input

• 5 V, 3 A
  9 V, 3 A
  12 V, 3 A
  15 V, 3 A
  20 V, 3 A

• Output (charging)

• 5 V, 2 A

• Charging Type

• 3 batteries charged simultaneously

  The number of batteries that can be charged simultaneously depends on the power of the charger used. Using a charger of more than 45 W allows for charging three batteries at once while using a charger of less than 45 W can only charge two batteries simultaneously. Refer to the charging protocols supported by the charger.

• Compatibility

• DJI Neo Intelligent Flight Battery
