VDC2 Pro Detection Jamming Integrated System
Note - All international orders outside the U.A.E. will receive a VAT and Tax discount.
TerjinThe VDC2 Pro Detection Jamming Integrated System is an advanced counter-drone platform designed for comprehensive airspace protection. It integrates detection, positioning, identification, and jamming into a single solution, enabling security teams to detect and neutralize drone threats in real time.
Using passive RF detection technology (100MHz–6GHz), the system can identify drone signals without emitting interference, ensuring covert and reliable monitoring. It provides real-time positioning of both drones and their operators, enhancing situational awareness and response capabilities.
With 12-frequency-band coordinated jamming, the VDC2 Pro can effectively disrupt control and navigation signals of various drone types, including DJI, Autel, FPV, and custom UAVs.
Its flexible deployment options—vehicle-mounted or fixed installation—make it suitable for a wide range of environments, from mobile security operations to permanent infrastructure protection.
Key Features
All-in-One Detection & Jamming System
- Combines detection, identification, localization, and jamming
- Enables full counter-drone workflow in a single platform
Wideband Passive Detection
- Frequency Range: 100MHz – 6GHz
- Passive RF sensing ensures no signal emission and high concealment
Long-Range Detection & Tracking
- Detection Range: 1 – 5 km (environment dependent)
- Provides real-time drone tracking and positioning
Multi-Band Jamming Capability
- Jamming Range: 0.5 – 3 km
- Covers 12+ frequency bands (180MHz – 5.8GHz)
- Effectively neutralizes control and navigation signals
Drone & Pilot Localization
- Identifies drone position and controller location
- Location accuracy up to ~10 meters
Automatic Detection-to-Jamming Linkage
- Automatically triggers countermeasures upon detection
- Reduces response time and improves operational efficiency
Multi-Target Detection
- Detects and tracks 10+ drones simultaneously
Advanced Drone Identification
- Identifies drone model and serial number (protocol dependent)
- Supports whitelist/blacklist classification for controlled engagement
Flexible Deployment
- Vehicle-mounted for mobile operations
-
Fixed installation for permanent site protection
Technical Highlights
- Product Name: VDC2 Pro Detection Jamming Integrated
- Detection Frequency: 100MHz – 6GHz
- Detection Range: 1 – 5 km
- Jamming Range: 0.5 – 3 km
- Location Accuracy: ~10 m
- Multi-Target Detection: ≥10 drones
- Jamming Bands: 180MHz – 5.8GHz (multi-band)
- Work Modes: Passive detection + RF jamming
- Deployment: Vehicle-mounted / Fixed installation
