Aircraft
Net Weight (with propellers and RTK module)
951 g
Max Takeoff Weight
1,050 g
Dimensions (Folded/Unfolded)
Folded (without propellers): 223×96.3×122.2 mm (Length×Width×Height)
Unfolded (without propellers): 347.5×283×139.6 mm (Length×Width×Height)
Diagonal Length
Diagonal: 380.1 mm
Max Ascent Speed
6 m/s (Normal Mode)
8 m/s (Sport Mode)
Max Descent Speed
6 m/s (Normal Mode)
6 m/s (Sport Mode)
Max Flight Speed (at sea level, no wind)
15 m/s (Normal Mode)
Flying forward: 21 m/s, flying sideways: 20 m/s, flying backwards: 19 m/s (Sport mode)
Max Wind Speed Resistance
12 m/s
Max Take-off Altitude Above Sea Level
6000 m (without a payload)
Max Flight Time (without wind)
43 minutes
Max Hover Time (without wind)
37 minutes
Max Flight Distance
32 km
Max Pitch Angle
30° (Normal Mode)
35° (Sport Mode)
Max Angular Velocity
200°/s
GNSS
GPS + Galileo + BeiDou + GLONASS (GLONASS is supported only when RTK module is enabled)
Hovering Accuracy Range
Vertical: ±0.1 m (Vision Positioning enabled); ±0.5 m (GNSS Positioning enabled); ±0.1 m (D-RTK enabled)
Horizontal: ±0.3 m (Vision Positioning
RGB Camera
Image Sensor
4/3 CMOS
Effective Pixels: 20 MP
Lens
FOV: 84°
Equivalent focal length: 24 mm
Aperture: f/2.8 to f/11
Focus: 1 m to ∞
ISO Range
100-6400
Shutter speed
Electronic shutter: 8-1/8000 s
Mechanical shutter: 8-1/2000 s
Max Image Size
5280×3956
Photo Shooting Mode
Single shot: 20 MP
Timelapse: 20 MP
JPEG: 0.7/1/2/3/5/7/10/15/20/30/60 s
JPEG + RAW: 3/5/7/10/15/20/30/60 s
Panorama: 20 MP (original material)
Video Resolution
H.264:
4K: 3840×2160@30fps
FHD: 1920×1080@30fps
Max Video Bitrate
4K: 130Mbps
FHD: 70Mbps
Supported File System
exFAT
Image Format
JPEG/DNG (RAW)
Video Format
MP4 (MPEG-4 AVC/H.264)
Multispectral Camera
Image Sensor
1/2.8-inch CMOS, effective pixels: 5 MP
Lens
FOV: 73.91° (61.2° x 48.10°)
Equivalent focal length: 25 mm
Aperture: f/2.0
Focus: Fixed Focus
Multispectral Camera Band
Green (G): 560 ± 16 nm;
Red (R): 650 ± 16 nm;
Red Edge (RE): 730 ± 16 nm;
Near infrared (NIR): 860 ± 26 nm;
Gain Range
1x-32x
Shutter Speed
Electronic Shutter: 1/30~1/12800 s
Max Image Size
2592×1944
Image Format
TIFF
Video Format
MP4 (MPEG-4 AVC/H.264)
Photo Shooting Mode
Single shot: 5 MP
Timelapse: 5 MP
TIFF: 2/3/5/7/10/15/20/30/60 s
Video Resolution
H.264
FHD: 1920 x 1080@30fps
Video content: NDVI/GNDVI/NDRE
Max Video Bitrate
Stream: 60 Mbps
Gimbal
Stabilization System
3-axis mechanical gimbal (tilt, roll, pan)
Mechanical Range
Tilt: -135° to 45°
Roll: -45° to 45°
Pan: -27° to 27°
Controllable Range
Tilt: -90° to 35°
Pan: Uncontrollable
Max Control Speed (tilt)
100°/s
Angular Vibration Range
±0.007°
Sensing System
Sensing System Type
Omnidirectional binocular vision system, with an infrared sensor at the bottom of the aircraft
Forward
Distance Measuring Range: 0.5 m to 20 m
Detection Range: 0.5 m to 200 m
Effective Obstacle Avoidance Speed: Flight Speed ≤15 m/s
FOV: Horizontal 90°, vertical 103°
Backward
Distance Measuring Range: 0.5 m to 16 m
Effective Obstacle Avoidance Speed: Flight speed ≤12 m/s
FOV: Horizontal 90°, vertical 103°
Lateral
Distance Measuring Range: 0.5 m to 25 m
Effective Obstacle Avoidance Speed: Flight speed ≤15 m/s
FOV: Horizontal 90°, vertical 85°
Upward
Distance Measuring Range: 0.2 m to 10 m
Effective Obstacle Avoidance Speed: Flight Speed ≤6 m/s
FOV: Front and rear 100°, left and right 90°
Downward
Distance Measuring Range: 0.3 m to 18 m
Effective Obstacle Avoidance Speed: Flight speed ≤6 m/s
FOV: Front and rear 130°, left and right 160°
Operating Environment
Front, Rear, Left, Right, Above: Surfaces with clear patterns and adequate lighting (> 15 lux, environments with normal indoor fluorescent light exposure)
Below: Surfaces with diffuse reflection material and a reflectivity of >20% (such as walls, trees, people, etc.); Adequate lighting (>15 lux, environments with normal indoor fluorescent light exposure)
Video Transmission
Video Transmission System
DJI O3 Image Transmission Industry Edition
Live View Quality
Remote Controller: 1080p/30fps
Operating Band [7]
2.400-2.4835 GHz
5.725-5.850 GHz
Max Effective Signal Distance (Unobstructed, No interference) [8]
FCC: 15 km
CE: 8 km
SRRC: 8 km
MIC: 8 km
Max Transmission Distance (Obstructed) [9]
Strong Interference (urban landscapes, residential areas, etc.): 1.5-3 km (FCC/CE/SRRC/MIC)
Medium Interference (suburban landscapes, city parks, etc.): 3-9 km (FCC), 3-6 km (CE/SRRC/MIC)
Weak Interference (remote fields, open farmland, etc.): 9-15 km (FCC), 6-8 km (CE/SRRC/MIC)
Max Download Speed
15 MB/s (with DJI RC Pro Industry Edition)
Latency (depending on environment and mobile device)
Approximately 200 milliseconds
Antennas
4 antennas, 2 transmitting and 4 receiving
Transmitter Power (EIRP)
2.4 GHz: <33 dBm (FCC), <20 dBm (CE/SRRC/MIC)
5.8 GHz: <33 dBm (FCC), <30 dBm (SRRC), <14 dBm (CE)
Other
Supports the DJI Cellular module
DJI RC Pro Enterprise Edition
Image Transmission System
DJI O3 Image Transmission Industry Edition
Max Effective Signal Distance (Unobstructed, No interference) [8]
FCC: 15 km
CE: 8 km
SRRC: 8 km
MIC: 8 km
Operating Band of Image Transmission [7]
2.400-2.4835 GHz
5.725-5.850 GHz
Antennas
4 antennas, 2 transmitting and 4 receiving
Operating Band of Image Transmission and Transmitter Power (EIRP)
2.4 GHz: <33 dBm (FCC); <20 dBm (CE/SRRC/MIC)
5.8 GHz: <33 dBm (FCC); <14 dBm (CE); <23 dBm (SRRC)
Wi-Fi Protocol
802.11 a/b/g/n/ac/ax
Support 2×2 MIMO Wi-Fi
Wi-Fi Operating Band [7]
2.400-2.4835 GHz
5.150-5.250 GHz
5.725-5.850 GHz
Wi-Fi Transmitter Power (EIRP)
2.4 GHz: <21 dBm (FCC); <20 dBm (CE/SRRC/MIC)
5.2 GHz: <27 dBm (FCC); <13 dBm (CE/SRRC/MIC)
5.8 GHz: <30 dBm (FCC); <13 dBm (CE/SRRC/MIC)
Bluetooth
Bluetooth 5.0
Supported Bluetooth profiles: SPP, GATT, A2DP, AVRCP
Bluetooth Operating Band [7]
2.402-2.480 GHz
Bluetooth Transmitter Power (EIRP)
<8 dBm
Display
5.5 inches
Resolution: 1920×1080
Battery
Capacity
5000 mAh
Voltage
7.2 V
Type
Lithium-ion 2S
Energy
36 Wh
Weight
310 g
Charging Temperature
5°C to 40°C
Max Charging Power
29 W
Charging Time
2 hours 35 minutes (when using the DJI 18W charger)
Charger
Input
100-240 V, 50/60 Hz, 1 A
Output
15 V=1.8 A or 5 V=3 A
Rated Power
28 W
Charging Hub
Input
5-8.4 V, 0-3 A
Output
4.35 V, 1.6 A
Rated Power
6.7 W
RTK Module
Dimensions
69.2×57.4×12.2 mm
Weight
41 g
Interface Type
USB-C
Power Consumption
Approx. 1.2 W
Horizontal Accuracy
Fixed RTK: 1 cm + 1 ppm
Vertical Accuracy
Fixed RTK: 1.5 cm + 1 ppm
