DJI BS100 Intelligent Battery Station – Powering Professional Aerial Operations

The DJI BS100 Intelligent Battery Station is a high-efficiency, industrial-grade charging solution engineered to support the DJI Matrice 400 Series. Designed with operational readiness and field performance in mind, this advanced station allows drone operators to maintain peak power levels throughout demanding missions by offering intelligent, safe, and rapid charging capabilities.

Whether you're managing multiple aerial missions per day or preparing for extended flight operations in rugged environments, the BS100 ensures your Matrice 400 fleet is always fully powered and ready to launch.

All-in-One Charging for Matrice 400 Series

The BS100 is specifically built to handle the power needs of the Matrice 400 platform. It supports simultaneous charging of:

• Up to 3 TB100 Intelligent Flight Batteries

• Up to 2 WB37 Remote Controller Batteries

This multi-channel charging capacity makes it the ideal choice for teams using multiple payloads, executing long-duration flights, or conducting complex survey missions. With the ability to charge several batteries in parallel, operational downtime is minimized, and mission efficiency is greatly enhanced.

Intelligent Charging Modes for Dynamic Mission Needs

The BS100 features multiple smart charging modes to match operational requirements:

• Fast Mode: Rapidly charges batteries to 90% capacity in approximately 45 minutes using 220V input, perfect for urgent mission redeployment.

• Standard Mode: Balances speed and battery longevity with moderate charging rates.

• Silent Mode: Reduces fan noise for quieter environments and extends charging time to around 110 minutes, suitable for indoor or night operations.

• Ready-to-Fly Mode: Prepares batteries to an optimal charge level and temperature so they’re mission-ready when needed.

These flexible charging options help extend battery life, optimize performance under different conditions, and align with the evolving needs of drone teams in the field.

Rugged Design for Harsh Environments

In industrial applications, charging equipment must be just as reliable as the drones they support. The DJI BS100 is built to endure challenging field conditions, with features including:

• Operating Temperature Range: -20°C to 40°C, allowing cold-climate or desert operations without performance loss.

• Rugged Construction: Built from durable materials to withstand transport, dust, and demanding environments.

• Integrated Handles and Compact Design: With dimensions of 605 × 410 × 250 mm and a weight of approximately 11.8 kg, the BS100 is both portable and durable.

This makes the BS100 suitable for deployment on construction sites, mountainous terrain, arid regions, or emergency response operations.

Intelligent Battery Management System

Safety and battery health are paramount for enterprise drone operations. The BS100 integrates a smart management system that:

• Monitors battery health in real-time

• Automatically balances cell voltages

• Prevents overheating and overcharging

• Displays battery diagnostics through DJI Pilot 2 interface

In cold conditions, the station activates the battery’s self-heating feature to bring it to optimal charging temperature. These safety protocols help prolong battery lifespan, reduce failure rates, and guarantee peak performance during critical missions.

Efficient Power Output and Connectivity

The BS100 provides a power output of:

• Up to 2.2kW per TB100 port

• 20V/3.25A via USB-C for charging controllers or compatible accessories

This allows drone operators to recharge both flight and control systems from a single station, reducing the need for multiple charging hubs or external adapters. The USB-C port is ideal for powering DJI remote controllers or mobile mission tablets.

Field Benefits of the BS100 Intelligent Charging Station

• Minimized Downtime: Rapid charging ensures your team can rotate batteries and continue missions with minimal interruptions.

• Mission Versatility: Ready-to-fly mode guarantees optimal performance even in rapidly evolving deployment scenarios.

• Integrated Safety Systems: Built-in diagnostics reduce the risk of in-field battery failure or operational delays.

• Reduced Equipment Load: One station for both flight and controller batteries cuts down the need for extra gear.

Whether conducting long-range surveillance, infrastructure inspection, aerial mapping, or emergency response, the BS100 is the essential companion for the DJI Matrice 400.

Use Case Scenarios

1. Surveying & Mapping Teams
For operations that require consistent battery cycles in remote locations, the BS100 ensures that survey crews can remain productive all day with quick recharge capabilities.

2. Emergency Response Units
First responders often work in dynamic conditions where mission readiness is critical. The BS100’s ready-to-fly and fast-charging modes ensure batteries are quickly available without thermal delays.

3. Industrial Inspections
Teams inspecting pipelines, towers, or large facilities benefit from minimal downtime between flights, thanks to simultaneous multi-battery charging.

4. Agricultural & Environmental Monitoring
In large-scale farm or forestry assessments, extended field time is vital. The BS100 helps maintain continuous operations across vast landscapes without returning to base.
