DJI Agras T50 Battery Charging Station (C10000)

(0 reviews)

Inhouse product

Enquire Now

Share

Enquire Now

The DJI Agras T50 Battery Charging Station (C10000) is a high-efficiency charging solution tailored for the DJI Agras T50 and T40 Intelligent Flight Batteries. With a robust 9,000 W power output, it significantly reduces downtime by fully charging batteries in approximately 9 to 12 minutes when connected to a 220 V outlet.

Key Features:

  • Rapid Charging: Delivers a maximum output current of 175 A, enabling swift battery replenishment to maintain continuous operations.

  • Intelligent Power Management: Monitors battery status in real-time, automatically adjusting current to ensure optimal charging efficiency and safety.

  • Comprehensive Safety Protections: Equipped with overvoltage, overcharge, undervoltage, and overtemperature protections to safeguard both the charger and batteries during operation.

  • Durable Design: Constructed to withstand the rigors of agricultural environments, ensuring reliable performance under various conditions.

  • Compatibility: Seamlessly integrates with DJI Agras T50 and T40 battery cooling stations, eliminating the need for additional adapters.

The C10000 Charging Station enhances operational efficiency for agricultural drone applications, providing a dependable and swift charging solution to support demanding field operations.

C10000 Intelligent Power Supply

  • Model Number

  • CSX702-9500
  • Dimensions

  • 400 × 266 × 120 mm
  • Weight

  • Approx. 11.4 kg
  • Input/Output

  • Input (Main): 220-240 VAC, 50/60 Hz, 24 A MAX
    Input (Auxiliary): 220-240 VAC, 50/60 Hz, 24 A MAX
    Output: 59.92 VDC MAX, 175 A MAX, 9000 W MAX
    Input (Main): 100-120 VAC, 50/60 Hz, 16 A MAX
    Input (Auxiliary): 100-120 VAC, 50/60 Hz, 16 A MAX
    Output: 59.92 VDC MAX, 60 A MAX, 3000 W MAX
  • Charging Time[11]

  • Fully charges a battery in 9 to 12 minutes (DB1560 Intelligent Flight Battery)
  • Protection Functions

  • Over-voltage, over-charge, under-voltage and over-temperature protection.
  • Charging Safety

  • AC wire protection, power wire protection, and charge connector protection
